          Pvc Garden Pipe Machine

          Pvc Garden Pipe Machine
          Product Code : PVCGPM 35
          Brand Name : R. D. ENGINEERING WORKS
          Product Description

          Incepted in 1989, we are amongst the prestigious and top manufacturers and exporters of Pvc Garden Pipe Making Machine. These machines are used to manufacture PVC garden pipes of diverse lengths and thicknesses. In order to manufacture high quality Pvc Garden Pipe Machine, our professionals employ advanced machines and utilize quality tested material procured from the authentic vendors. Furthermore, we offer these machines as per the needs of the clients.

          We are widely accepted name in industry in manufacturing and exporting PVC Water Pipe Machine. This machine is manufactured in compliance with international quality standards using premium quality components under the visionary guidance of our experienced professionals. Our offered machine is widely used for producing polyvinyl chloride water pipe, drainage pipe, etc. Provided machine is available in diverse specifications to complete the various needs of our clients. Moreover, this PVC Water Pipe Machine can be owned from us at rock-bottom prices.

          Products Features:

          • Rugged design
          • Less maintenance
          • Low-noise operation
          • Easy to operate

          Technical specification: -

          • Minimum-maximum out put : 130kgs/hr {depending upon material, rpm of machine & operating the machine}
          • Size range: 3 mm 40mm inner dia.
          • Raw material use :PVC compound.{extruding}
          • Rpm of machine : 20-72 /max

          EXTRUDER:

          • 90mm single screw extruder
          • mounted on heavy channel&sheet frame
          • Gearbox mounted(helical gearbox)
          • Motor mounted with motor frame.
          • Barrel cover mounted
          • Screw:90mm screw
          • Made by stainless steel material or ENB-41
          • Dully chrome
          • Polish for smooth flow.
          • L/D ratio :25:1
          • Barrel : approximate 90mm inner diameter
          • Made by nintrated material.
          • Gas nitrated.
          • Dully chrome
          • Water circulation through jacket by inlet& outlet pipes
          • Hoper settled on barrel
          • Raw material inlet mouth

          Heating system :

          • HEAT PROOFE HEATER are specifically designed and engineered to meet the ever-increasing demand for energy conservation and to improve operation efficiency.
          • Especially to heat the barrels on processing machinery.
          • Reduce the rate of heat radiation in the unit cool atmosphere.
          • Reduction in energy consumption of the machine by 20-40%
          • Reduce wattage of heater.
          • Good temp uniformity.
          • No. Of heater {zone} :4p zone(4x2=8p).
          • Fully flexible for easy installation.

          Heating load :12KW.(1.5x8=12)

          Hopper: round fabricated ss of capacity 40 kg

          Main drive : 20hp AC 1440-rpm motor of ABB make, C-section pulley fitted on shaft

          Transmission system :by V belt motor to gear box

          PVC Water Pipe Machine Head Specification:

          • Made by stainless steel material
          • It is nz center.
          • Direct mount on barrel plates.
          • Dye fitted on the master head
          • Atmosphere or comp. air pass on the head spindle
          • Nz fitted on the head spindle

          Dye & nozzle :3set of any size

          Dye setting: It is nz center. Centering screw to adjust gap are provided.
